OM4 24-core MPO/MTP® UPC to 2x MPO/MTP® UPC Multimode Conversion Patch Cord, Polarity B
OM4 24-core MPO/MTP® UPC to 2x MPO/MTP® UPC Multimode Conversion Patch Cord, Polarity B
- Description
- Features
- 实物展示
This product is an OM4 multimode 24-core MPO/MTP UPC fiber conversion patch cord using magenta OS2 cable, supporting 100G/400G high-speed data transmission. One end is a 24-core MPO female connector, and the other end converts into 2x 12-core MPO female connectors. The polarity B design meets the high-density breakout and interconnection needs of 100G/400G optical modules in data centers, suitable for 400G ZR/FR4 optical modules and MPO-24 breakout/distribution systems.
• OM4 ultra-high-speed transmission: 50/125μm laser-optimized fiber, 100G transmission distance up to 400m, 400G up to 150m.
• 24-core to 2×12-core conversion: one 24-core MPO female end converts into 2 independent 12-core MPO female connectors, supporting 100G/400G high-speed breakout interconnection.
• Polarity B standard layout: precise polarity B correspondence between 24-core MPO and dual 12-core MPO, plug-and-play without additional patch cords.
• High-density cabling optimization: a single 24-core patch cord replaces traditional multiple patch cords, greatly simplifying rack cabling and improving space utilization.
