OM3 12-core MPO/MTP UPC to MPO UPC Multimode Patch Cord, Polarity B
OM3 12-core MPO/MTP UPC to MPO UPC Multimode Patch Cord, Polarity B
- Description
- Features
- 实物展示
This product is an OM3 multimode 12-core MPO/MTP UPC fiber patch cord using aqua OFNR/OFNP cable, supporting 10G/40G/100G Ethernet high-speed transmission. One end is a standard MPO female connector, and the other end branches into independent MPO female connectors. The polarity B design meets the high-density cabling requirements of data centers and is suitable for 40G/100G QSFP+/QSFP28 optical module interconnection and MPO breakout/distribution scenarios.
• OM3 multimode high capacity: 50/125μm laser-optimized fiber, 10G transmission distance up to 300m, supports 40G/100G high-speed interconnection.
• Flexible 12-core breakout configuration: one MPO female end breaks out into independent MPO female connectors, supporting flexible 1+1 or 1+N breakout/distribution.
• Polarity B precise alignment: Key-Up/Key-Down alternating design ensures correct polarity for multi-core parallel transmission.
• Low insertion loss: UPC precision polishing, insertion loss ≤0.5dB, return loss ≥50dB, stable and reliable signal transmission.
